Eaton Bypass Switch

  • Part: 1381783
  • Model: MBP3KI
$442.00
FREE DELIVERY

Availability

In Stock

The Eaton HotSwap MBP series is made of versatile, flexible 2U PDUs designed to add high availability to UPSs up to 3,000 VA. Any UPS connected to a HotSwap MBP can be replaced for maintenance or upgrade purposes without interrupting the power supply to the protected devices. As a unique feature, they can be screwed at the back a Pulsar UPS, either front-facing or rear-facing, on the left or right hand side, for maximum versatility. They offers multiple mounting options for rack enclosures, wall mounting or connection at the rear of a UPS, whatever its brand.

Features and Benefits

  • Adds high availability to UPSs up to 3,000 VA
  • Can be rackmounted, wallmounted or connected at the rear of an Eaton UPS in 3 different ways
  • 2U versatile power distribution unit
  • Easy plug-in connectivity
  • Universal solution

  • General Information
    • Manufacturer
    • Eaton Corporation
    • Manufacturer Website Address
    • http://www.eatoncorp.com.au
    • Brand Name
    • Eaton
    • Product Series
    • MBP
    • Product Type
    • Bypass Switch

  • Technical Information
    • Plug/Connector Type
    • IEC 60320 C20
    • Receptacles
    • 1 x IEC 320-C19
    • 6 x IEC 60320 C13
    • Protection Type
    • Short Circuit
  • Power Description
    • Load Capacity (VA)
    • 3 kW
    • Input Voltage
    • 230 V AC
  • Physical Characteristics
    • Form Factor
    • Wall/Rack-mountable
    • Rack Height
    • 2U
    • Height
    • 52 mm
    • Width
    • 483 mm
    • Depth
    • 120 mm
  • Miscellaneous
    • Compatibility
    • Eaton 9PX UPS (1000-3000W)
